Low Cement Refractory Castable


Low Cement Refractory Castable

Calcium aluminate cement as bonding agent, the CaO content is below 2.5%, the castable is called low cement refractory castable. According to the USA ASTM Standard, CaO content is between 1.0-2.5%, called low cement refractory cement, CaO content is below 1.0%, called super low cement refractory cement.

Low Cement Refractory Castable Feature

 1.High refractoriness, high strength at high-temp state, Strong erosion of smelt slag resistance.

2.Lower porosity, higher density

3.Strength increased gradually with the temperature rising.

4.Can make the self-flowing castable, or irrigating by pump castable.

 Low Cement Refractory Castable Application

 Widely used in the waste in the waste Incinerator, such as pipe wall and other zones.


Product Details



Low Cement Refractory Castable


Calcium aluminate cement as bonding agent, the CaO content is below 2.5%, the castable is called low cement refractory castable. According to the USA ASTM Standard, CaO content is between 1.0-2.5%, called low cement refractory cement, CaO content is below 1.0%, called super low cement refractory cement.


Low Cement Refractory Castable Feature



1.High refractoriness, high strength at high-temp state, Strong erosion of smelt slag resistance.

2.Lower porosity, higher density

3.Strength increased gradually with the temperature rising.

4.Can make the self-flowing castable, or irrigating by pump castable.



Low Cement Refractory Castable Application



Widely used in the waste in the waste Incinerator, such as pipe wall and other zones.



Technical Dates of Low Cement Refractory Castable



              ITEM



PROPERTY

Low cement

castable

HXSH-1

Low cement

castable

HXSH-2

Low cement

self-flow

cement HXSSH-1

Low cement

self-flow

cement HXSSH-2

Al2O3    %  ≥

9

25

3

23

SiC      %  ≥

83

49

85

41

A.  P.    %  ≤

14.5

14.5

18

18

B.  D.  g/cm3 ≥

2.45

2.40

2.70

2.50

M.O.R @110℃×24h

(MPa)

7

6

5.0



6

Thermal Conductivity

1000(W/(m*K))

6.9

4.7

10.5

4.0



*They are typical values in this table, not a basis for order.
