Refractory Brick

AZS Bricks

1.High Temperature and Erosion Resistance

2.High Compactness Property

3.Good Mechanical Property and Wear Resistance



Product Details


AZS Refractory Bricks Introdution



AZS Brick is a kind of fused cast zirconia-corundum refractory brick which is short writing of abbreviation that AZS from “A” of Al2O3, “Z” of ZrO2 and “S” of SiO2. Such as No. 33 fused cast zirconia-corundum refractory brick adopts the “AZS-33#” as its abbreviation, No. 36 fused cast zirconia-corundum refractory brick adopts the “AZS-36#” as its abbreviation and No. 41 fused cast zirconia-corundum refractory brick adopts the “AZS-41#” as its abbreviation.


Application of AZS Refractory Bricks



The AZS bricks are mainly applied for the top and bottom structure of melting chamber. Such as melting tank, the tank wall brick, the paving brick, the forehearths and so on. The high corrosion part shall be AZS 41#, such as the feeding part, the throat, the bubble brick, the furnace weir, the burner block, the tongue brick the discharging part and so on.


Technical Dates of AZS Refractory Bricks



Item

AZS-30

AZS-26

AZS-20

AI2O3(%) ≥

48

65

70

ZrO2(%) ≥

30

26

20

Refractoriness℃ ≥

1790

1790

1790

B.D g/cm3≥

3.2

3.1

3.0

A.P (%)≤

18

17

18

C.C.S.(MPa)≥

90

90

80

R.U.L ℃≥

1650

1650

1650
